Model BY - M1200B
Technical parameters
18 control channel, standard DMX512 signal
LCD liquid crystal display system in English, can be very intuitive set personalized features.
Color plate 2, white + 7 color, one-way rainbow effect
Fixed pattern plate of 1, has the pattern jitter, one-way flow effect
1, pattern plate rotating with pattern jitter, one-way flow effect
Prism prism plate 1, a variety of choice, the phantom effect of god
Effect 1, temperature (6000 k), temperature (3200 k), atomization, prism effect
0 ~ 100% linear mechanical dimmer, stroboscopic speed 1 ~ 12 times per second, built-in frequency ShanHong function.
Electric aperture of 5-100% linear calibration beam size,
Beam Angle: 12 ° ~ 24 ° linear infinite adjustment
Electronic linear focusing 2 meters to infinite
Level 450 °, 16 bit resolution
Horizontal, vertical, using light lotus root reset system,
After the accident occurs misoperation, can automatically retrieve place
Good heat dissipation system fully, and overheating protection measures
With photoelectric detection, light soaking time delay, the lamp and control system has
Protection function, improve the stability of lamps and lanterns.
Through external console or light devices end plate control window,
Edit storage to run the program to the CPU in the body,
No programming controller can also run or run a program, can store eight scenes.
Security code is set for the customer, can display light bulbs and lamps and lanterns use time
