Technical specifications
Model BY - B200
16 channels.
Bulb models: Philips MSD Platinum 5 r or YODN 5 r power: 189 w flux is 189 lm, color WenKeDa 8500 k.
Beautiful dot matrix display, four light touch switch, reversing 180 ° display.
Color plate: a color plate, each color plate consists of 14 shade,
Pattern plate: 14 design effect.
Round effect: a rotating prism, effect of mobile, atomization function.
0-100% mechanical dimmer, support mechanical stroboscopic and adjustable speed stroboscopic effect, frequency ShanHong support functions.
Lens group of optical system, electric focus, beam Angle 0 ° ~ 4.
Using photoelectric reposition system, after the misoperation accident happen, can automatically retrieve reset.
Level 540 °, 8 bit / 16 bit resolution
250 ° vertically, 8 bit / 16 bit resolution.
Overheating protection.
Power supply: 200-240 - v, 50/60 hz
Power: 200 w
IP protection grade: IP20
Inductance ballasts and AC/DC switching power supply.
Size: 523 (length) x 337 (width) x 511 mm (high)
Net weight: 19.5 KG
